MILESIGHT - LoRaWan office/seat occupancy PIR sensor

Introducing the VS340-868M

The VS340 is an occupancy detection sensor developed by Milesight for precise monitoring of workstations and seating in open-space or collaborative environments. Thanks to its PIR (passive infrared) detection technology, it is able to detect human movement in the immediate vicinity, making it possible to determine the actual occupancy of a space.

Communication takes place via the LoRaWAN® network, making the sensor particularly suitable for intelligent buildings requiring extensive coverage without complex network infrastructure. Its wireless design, powered by a high-capacity lithium battery (4000 mAh), guarantees autonomy of up to 5 years, reducing maintenance requirements.

Compact, discreet and easy to install, the VS340 integrates perfectly into the management of intelligent spaces, while ensuring simplified configuration via NFC thanks to the Milesight ToolBox mobile application.

VS340-868M applications

• Supervision of shared offices (flex office)
• Presence counting in meeting rooms
• Analysis of resource use in public facilities
• Control of disinfection or cleaning scenarios based on actual occupancy
• Integration with building management systems (BMS) via LoRaWAN®
• Functions
• Presence detection by high-sensitivity PIR sensor
• Wide detection field:
• 107° H / 107° V, up to 1 meter
• Secure transmission on LoRaWAN® network, class A
• Local configuration via NFC (Milesight ToolBox mobile application)
• Support for Milesight D2D protocol for direct communication between equipment
• LED status indication
• Quick installation via screws or double-sided adhesive tape supplied

VS340-868M technical specifications

• Model: VS340
• Sensor type: PIR (Passive Infrared)
• Recognition rate: up to 95%
• Detection angle: 107° horizontal / 107° vertical
• Detection distance: up to 1 meter
• Protocol :
• LoRaWAN® (Class A), D2D support
• Supported bands
• : CN470 / IN865 / EU868 / RU864 / US915 / AU915 / KR920 / AS923
• Power supply: 1 ER18505 4000 mAh battery
• Autonomy: approx. 5 years (normal use)
• Protection rating: IP30
• Operating temperature :
• -20°C to +60°C
• Humidity: 0% to 95% non-condensing
• Dimensions: 73 × 73 × 26 mm
• Weight: 90 g
• Material: PC+ABS flame-retardant, white
